Feed Assembly BG 006 170 53 aF NSS for Sandvik DL2720
The feed assembly BG 006 170 53 aF NSS for the Sandvik DL2720 longhole drill is available from stock with fast worldwide delivery.
Components included in Feed Assembly BG 00617053 aF NSS
| Ref. | Part No. | Alt. No. | Description | Qty |
|---|---|---|---|---|
| 1 | 550 432 58 | 55043258 | Beam, Feed | 1 |
| 2 | 550 593 28 | 55059328 | Cylinder | 1 |
| 3 | 550 483 02 | 55048302 | Carriage Assembly | 1 |
| 4 | 320 776 08 | 32077608 | Strip | 2 |
| 5 | 330 016 98 | 33001698 | Slipper Pad | 8 |
| 6 | 322 278 48 | 32227848 | Wheel, Idler | 1 |
| 8 | 550 435 33 | 55043533 | Wire Rope | 4 |
| 9 | 550 011 12 | 55001112 | Support | 1 |
| 10 | 321 519 98 | 32151998 | Guide, Hose | 1 |
| 11 | 550 187 80 | 55018780 | Support, Hose | 1 |
| 12 | 550 434 43 | 55043443 | Lug | 1 |
| 13 | 236 223 18 | 23622318 | Latch | 1 |
| 14 | 550 437 79 | 55043779 | Nut | 2 |
| 15 | 550 437 69 | 55043769 | Nut | 2 |
| 17 | 550 439 18 | 55043918 | Plate | 1 |
| 19 | 321 517 35 | 32151735 | Cable Entry Plate | 1 |
| 20 | 550 089 51 | 55008951 | Bar | 2 |
| 21 | 550 089 53 | 55008953 | Conduit | 2 |
| 23 | BG 006 170 42 NSS | BG00617042NSS | Valve Assembly | 1 |
| 24 | 550 288 50 | 55028850 | Slipper Pad | 2 |
| 25 | 550 427 30 | 55042730 | Rod Retainer | 1 |
| 26 | 209 105 78 | 20910578 | Plate | 2 |
| 27 | 204 279 28 | 20427928 | Plate, Locking | 3 |
| 28 | BG 002 367 33 | BG00236733 | Pin | 1 |
| 29 | 204 551 78 | 20455178 | Bushing, Bearing | 2 |
| 30 | 321 834 51 | 32183451 | Cable Entry Plate | 1 |
| 35 | 817 095 99 | 81709599 | Adapter | 4 |
| 36 | 817 179 09 | 81717909 | Straight Thread Adapter | 2 |
| 37 | 816 768 29 | 81676829 | Straight Thread Adapter | 2 |
| 40 | 207 256 58 | 20725658 | Sign | 1 |
| 45 | 550 441 37 | 55044137 | Guide Wash Mounting | 1 |
| 46 | 887 319 09 | 88731909 | Hexagon Head Bolt | 4 |
| 47 | 550 435 93 | 55043593 | Lever | 1 |
| 48 | 550 438 00 | 55043800 | Lever | 1 |
| 49 | 550 438 18 | 55043818 | Shaft | 2 |
| 50 | 453 689 98 | 45368998 | Bushing, Bearing | 2 |
| 51 | 550 876 04 | 55087604 | Bushing, Bearing | 2 |
| 53 | 572 102 40 | 57210240 | Nipple, Grease | 3 |
| 54 | 572 106 50 | 57210650 | Nipple, Grease | 1 |
| 55 | 801 811 49 | 80181149 | Plug | 3 |
| 202 | 800 824 29 | 80082429 | Hexagon Head Screw | 4 |
| 204 | 800 470 59 | 80047059 | Hexagon Head Screw | 5 |
| 263 | 800 537 39 | 80053739 | Hexagon Head Screw | 12 |
| 264 | 442 218 50 | 44221850 | Hexagon Head Screw | 12 |
| 271 | 800 469 99 | 80046999 | Hexagon Head Bolt | 2 |
| 275 | 800 540 59 | 80054059 | Hexagon Head Bolt | 6 |
| 287 | 800 543 39 | 80054339 | Hexagon Head Bolt | 24 |
| 289 | 443 005 10 | 44300510 | Hexagon Head Bolt | 2 |
| 517 | 801 775 89 | 80177589 | Nut, Lock | 24 |
| 519 | 800 485 09 | 80048509 | Nut, Hexagon | 12 |
| 551 | 851 281 89 | 85128189 | Washer, Lock, Double | 4 |
| 553 | 851 068 09 | 85106809 | Washer, Lock, Double | 9 |
| 555 | 850 687 49 | 85068749 | Washer, Lock, Double | 48 |
| 600 | 455 332 90 | 45533290 | Screw | 4 |
| *33 | 550 425 59 | 55042559 | Rail, Slide | 2 |
| *34 | 550 425 60 | 55042560 | Rail, Slide | 2 |
If the required component is not listed on this page, contact our team for assistance. Our specialists will help you identify compatible feed system spare parts and components for Sandvik DL2720.
