Part Number: 5112 2877 97 (5112287797)
The pump 5112 2877 97 (5112287797) is designed for the hydraulic system of the Epiroc Boomer L2D drilling rig. It provides stable pressure and flow for drilling, feed, and positioning functions, ensuring reliable performance under demanding tunneling conditions.
| Ref. | Part No. | Alt. No. | Qty | Description |
|---|---|---|---|---|
| 1 | 5112 2877 97 | 5112287797 | 1 | Hydraulic Pump |
| 2 | 5112 2878 09 | 5112287809 | 1 | Actuator |
| 3 | 5112 2878 51 | 5112287851 | 1 | Gasket |
| 1 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 2 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 3 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 4 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 6 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 7 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 8 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 9 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 10 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 11 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 12 | 5112 2878 41 | 5112287841 | 1 | Shims |
| 15 | 3217 9203 25 | 3217920325 | 1 | Roller Bearing |
| 16 | 5112 2878 42 | 5112287842 | 1 | Roller Bearing |
| 17 | 5507 8719 00 | 5507871900 | 2 | Nut |
| 20 | 5112 2878 43 | 5112287843 | 1 | Sealing |
| 21 | 5112 2878 44 | 5112287844 | 1 | O-Ring |
| 22 | 3222 3278 21 | 3222327821 | 1 | O-Ring |
| 23 | 5112 2878 45 | 5112287845 | 1 | O-Ring |
| 25 | 5112 2878 46 | 5112287846 | 1 | Locking Ring |
| 27 | 5507 8719 00 | 5507871900 | 4 | Nut |
| 29 | 5112 2878 47 | 5112287847 | 1 | Stop Ring |
| 33 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 34 | 5507 8719 00 | 5507871900 | 1 | Nut |
| 37 | 5507 8719 00 | 5507871900 | 1 | Nut |
TechCom supplies the full range of spare parts for Boomer L2D, ensuring long service life and reliable operation of your drilling equipment.
