Drilling Rig Sandvik 160D
The Sandvik 160D is a rotary blasthole drilling rig developed for surface mining and quarry operations requiring dependable performance and cost efficiency. Manufactured according to Sandvik’s proven design philosophy, the machine combines a rugged crawler carrier with a revolving superstructure supporting all major systems and components.
Technical Specifications
| Parameter | Value |
|---|---|
| Drilling Method | Rotary drilling with tricone bits |
| Hole Diameter | 127–171 mm |
| Drill Pipe Length | 7.62 m |
| Maximum Hole Depth | 30 m |
| Maximum Pulldown Force | 133 kN |
| Bit Load | 142 kN |
| Engine | Cummins NTA-855 diesel engine, 295 hp |
| Compressor Capacity | 17.3 m³/min at 7 bar (350 psi) |
| Pipe Feed Speed | 0–21 m/min |
| Pipe Hoisting Speed | 0–49 m/min |
| Operating Weight | 32,000 kg |
