Drilling Rig Epiroc DM25
The DM-25 is a versatile mid-range rig engineered for productive drilling in mining and quarrying. It handles both rotary and down-the-hole (DTH) methods with a single-pass depth of up to 15.2 meters, minimizing time between cycles.
It runs on a Caterpillar C15 or Cummins QSX diesel engine with output ranging from 425 to 525 hp. The hydraulic system generates 111 kN of pulldown and pullback force, while 11,300 kg of bit load ensures solid contact in hard formations.
Its crawler-based chassis allows smooth navigation over irregular and rough terrain. Inside the cab, operators benefit from insulation, filtered air, and a clear layout of all controls, improving safety and ease of use during long shifts.
The rig can be upgraded with dust suppression, angle drilling (up to 15°), automatic greasing, and cold-weather support. Both 12.2 and 15.2 meter towers are available, compatible with a range of kelly bars for uninterrupted drilling.
Key Advantages
- Single-pass depth up to 15.2 meters
- Optional high-pressure compressor for DTH use
- No need for special transport equipment
- Comfortable, well-ventilated operator cabin
- Stable movement on uneven terrain
Technical Specifications
| Parameter | Value |
|---|---|
| Engine | Caterpillar C15 / Cummins QSX (425–525 hp) |
| Drilling Method | Rotary and DTH, single-pass |
| Hydraulic Pulldown Force | 111 kN |
| Hydraulic Pullback Force | 111 kN |
| Bit Load | 11,300 kg |
| Drilling Depth | 12.2–15.2 m |
| Hole Diameter | 102–178 mm |
| Rotary Torque | 4.7 kN·m |
| Compressor Output | 900 cfm @ 7.6 / 24 bar |
| Operating Weight | 28 t |
