Drilling Rig Epiroc SmartROC C50

The SmartROC C50 by Epiroc is a compact, high-efficiency surface rig built for demanding operations in quarrying and mining. It features the advanced COPROD system, delivering exceptional hole straightness and productivity while reducing fuel consumption and component wear.

The COPROD system pairs a spinning drill tube with a free-floating core rod to transfer energy effectively. Rotation is provided by the outer tube, while the internal rod directs impact force and penetration pressure straight into the rock mass. Flushing air flows between both elements, reaching the bit face to ensure clean and accurate holes.

Why Choose SmartROC C50 with COPROD

• Compatible with COPROD 76 mm, 89 mm, and 102 mm string sizes
• Handles blast hole diameters from 90 mm to 140 mm
• Fitted with the powerful COP 3060CR hydraulic hammer
• Direct energy transfer with no threaded loss
• Reduced fuel usage per meter advanced
• Minimal wear and long-lasting performance
• Precise and stable performance in fractured ground

Optimized Percussion System

During operation, internal rods stack vertically within the tubes, transmitting force directly to the rock without thread interfaces. This design enhances overall efficiency, reduces fuel demands, and lowers mechanical stress on parts.

SmartROC C50 offers the perfect balance of accuracy and speed, making it ideal for surface applications that demand productivity and sustainability.

Need help choosing the right configuration? Our team will help configure the right solution and provide accurate pricing. Request a consultation.
