Grinding Machine Grind Matic Manual B Epiroc

Epiroc Grind Matic Manual B Grinding Machine

Epiroc Grind Matic Manual B is a portable air-powered grinding machine designed for on-site grinding of threaded and tapered button bits. Equipped with Epiroc diamond grinding wheels, it is suitable for spherical, ballistic and Trubbnos button profiles. The machine is mounted in a robust box with wheels and handles, making it mobile and easy to set up for surface and underground drilling operations.

Main Advantages

  • Portable design – mounted in a transport box with wheels and handles for convenient use on site.
  • Efficient grinding – restores worn carbide buttons to support consistent drilling performance and bit life.
  • Multiple button profiles – suitable for spherical, ballistic and Trubbnos buttons.
  • Recirculated cooling – a separate 10-liter water container provides efficient cooling during grinding.
  • Medium grinding capacity – designed for approximately 10–25 bits per day.

Technical Specifications

Power source Pneumatic
Maximum air pressure 7 bar (101.5 psi)
Air consumption 15 l/s
Coolant container 10 l
Grinding capacity 10–25 bits per day
Maximum diameter, threaded bits 127 mm (5")
Maximum diameter, retrac bits 127 mm (5")*
Maximum diameter, tube drilling 152 mm (6")*
Weight, excluding packaging 55 kg
Weight, including packaging 90 kg
Transport dimensions 1200 × 800 × 850 mm

* Large clamping device required.

Accessories Included in Delivery

  • Handheld grinder, 30,000 rpm
  • 4 centering fingers
  • 4 mm Allen key
  • 2 open-end spanners, 14 mm
  • Protective goggles
  • Operator's instructions and spare parts list

Grinding wheels and bit holders are required separately. TechCom supplies grinding equipment, accessories and Epiroc spare parts for the maintenance of rock drilling equipment and tools.

Contact us to request Epiroc grinding accessories, Epiroc spare parts or technical assistance in selecting the appropriate grinding equipment.
