TL-200 Portable Light Tower: lighter, brighter and fast to deploy
The TL-200 portable light tower is a compact LED tripod mast designed for quick setup by a single operator. The foldable telescopic mast, with an adjustable height from 1.0 m to 2.3 m, and a lightweight light head make it suitable for construction sites, railway and road maintenance, mining, infrastructure works and emergency applications.
With its low weight (less than 6 kg without battery), robust tripod structure and long battery endurance, the TL-200 is an excellent choice wherever a mobile lighting solution with rapid deployment and stable performance is required. The tower is available in a single-head version (battery-powered) and a brighter dual-head version with both battery and mains power options.
Main features of the TL-200 light tower
The TL-200 has been engineered for practical field use, combining easy transport, fast deployment and flexible light output control:
- Fast deployment: unfolding or folding the TL-200 takes just two steps and less than 10 seconds; the lamp head can be locked at any height using the mast clamp.
- Stable tripod base: the wide tripod design provides good stability, while optional ground pegs can be used to secure the legs against wind and vibration.
- Single- or dual-head options: the single-head version is battery-powered; the dual-head version supports both battery operation and AC mains power (with X1-75-56BH driver).
- High light output: battery operation offers up to 4,000 lm (single-head) or 6,000 lm (dual-head), while AC operation on the dual-head version provides stepless dimming up to 12,000 lm.
- Multiple lighting modes: Eco, Balanced, Standard and Turbo modes help balance brightness and runtime depending on the task.
- Smart usability details: dual rainproof USB outputs for charging two devices at once, and a hook that can also serve as a phone stand while charging.
Technical specifications
| Model | TL-200 |
|---|---|
| Mast height | 1.0–2.3 m |
| Weight (without battery) | < 6 kg (approx.) |
| Power supply | D24 series battery packs; AC mains (dual-head version, with X1-75-56BH driver) |
| Light head options | Single-head (battery only) or dual-head (battery and AC) |
| Luminous flux, single-head (battery) | up to 4,000 lm |
| Luminous flux, dual-head (battery) | up to 6,000 lm |
| Luminous flux, dual-head (AC) | 0–12,000 lm, stepless dimming |
| Brightness modes (battery) | Eco / Balanced / Standard / Turbo |
| Typical runtime with D24-54 battery | up to 22 hours in Eco mode (approximate) |
| Typical runtime with D24-100 battery | up to 45 hours in Eco mode (approximate) |
| Typical applications | Construction, railway and road maintenance, mining, infrastructure work, emergency and rescue operations, camping and sports |
TL-200 light towers and TechCom solutions
The TL-200 portable light tower enhances the TechCom portfolio of lighting solutions for construction and mining projects where mobility, fast deployment and reliable illumination are essential. Depending on the configuration, the TL-200 can be used as a compact task light, area lighting solution or part of a wider site lighting system.
If you need to select a light tower for a specific project or order spare parts for equipment already in operation, please contact the TechCom team for technical advice and a tailored commercial offer.
Alongside compact solutions such as the TL-200, TechCom supplies diesel and electric Atlas Copco light towers designed to illuminate large open areas, warehouses, construction sites and mining operations.
TechCom also offers a dedicated spare parts catalog for auxiliary machinery and equipment, including a wide range of genuine and OEM components for pumps, compressors and other mining equipment.
