Lighting Tower G-COMIN TL-100
TL-100 Portable Light Tower: a compact solution for work in any conditions
The TL-100 light tower is a compact, portable LED light tower with battery power, designed for quick deployment by a single operator. The telescopic mast with an extendable height of up to 1.4 m and a lightweight light head ensures convenient operation on construction sites, during emergency work, infrastructure maintenance and in field conditions.
Thanks to its low weight (less than 2.9 kg without battery), impact-resistant housing and high level of dust and moisture protection, the TL-100 is suitable for use in harsh environments where mobile light sources with long battery runtime are required.
Main features of the TL-100 light tower
The TL-100 combines easy transport, fast setup and flexible light control:
- Instant deployment: raise the light head to a height of up to 1.4 m for automatic locking in just one second; a light downward push folds and locks the unit in transport position.
- Adjustable light head: smooth, tool-free tilt angle adjustment with damping for precise positioning of the light beam.
- Four lighting modes: Eco, Balanced, Standard and Turbo with luminous flux up to 4000 lm and optimised battery runtime.
- Low weight and portability: a single operator can handle the tower; a convenient carrying handle is provided.
- IP66 protection rating: resistance to dust, moisture and precipitation for operation in open areas and harsh conditions.
Technical specifications
| Model | TL-100 |
|---|---|
| Mast height | 0.9–1.4 m |
| Weight (without battery) | ≈ 2.9 kg |
| Power supply | D24 series battery packs |
| Luminous flux | 0–4000 lm (adjustable) |
| Brightness modes | Eco / Balanced / Standard / Turbo |
| Typical luminous flux by mode | Eco — 450 lm; Balanced — 1500 lm; Standard — 2500 lm; Turbo — 4000 lm |
| Runtime with D24-54 battery (typical) | up to 22+ hours in Eco mode (approximate) |
| Runtime with D24-100 battery (typical) | up to 44 hours in Eco mode; more than 8 hours in Standard mode (at 2500 lm) |
| Protection rating | IP66 |
| Typical applications | Construction, repair, road and railway maintenance, emergency and rescue operations, camping, sports |
| Package dimensions (approx.) | 930 × 245 × 260 mm |
| Package weight | ≈ 6.5 kg |
TL-100 light towers and TechCom solutions
The portable TL-100 light tower expands the TechCom range of solutions for construction and mining projects where mobility, autonomy and rapid deployment of site lighting are critical. The tower can be used as a standalone light source or as part of an integrated site lighting solution.
If you need to select a light tower for a specific project or order spare parts for equipment already in operation, please contact our team for technical advice and a commercial offer.
In addition to compact models, TechCom supplies diesel and electric Atlas Copco light towers designed to illuminate large open areas, warehouses, construction and mining sites.
TechCom also offers a spare parts for auxiliary machinery and equipment, including a wide range of genuine and OEM components for compressors, pumps and other mining equipment.
