Epiroc SB 302 Solid Body Hydraulic Breaker – 300 kg class (4.5–9 t carrier)
The Epiroc SB 302 solid body hydraulic breaker is designed for light to medium demolition, trenching, asphalt removal and scaling applications. Its slim and compact monobloc design combines high efficiency, reliable performance and easy maintenance, making it ideal for work in confined spaces such as inside buildings, along walls or in narrow trenches.
Technical specifications – Epiroc SB 302
| Parameter | Value |
|---|---|
| Carrier weight class | 4.5 – 9 t |
| Service weight | 300 kg |
| Tool diameter | 80 mm |
| Working tool length | 400 mm |
| Max. hydraulic input power | 20 kW |
| Oil flow rate | 50 – 80 l/min |
| Operating pressure | 100 – 150 bar |
| Impact rate | 600 – 1,400 bpm |
| Guaranteed sound power level | 119 dB(A) |
The Epiroc SB 302 features an energy recovery system, a maintenance-free high-pressure accumulator with patented diaphragm support, and optional ContiLube® II Micro automatic lubrication and water spraying system. Consult the hydraulic breaker Epiroc SB 302 spare parts catalog to identify compatible components and service kits.
