The Ulba-150I is a compact unit for pneumatic delivery of AN-based bulk explosives into boreholes and blast holes. Suitable for underground mining, it supports emulsion densities up to 1.35 g/cm³ and loading angles from 0° to 360°.
| Vacuum loading rate, kg/min | 100–150* |
| Material feed rate, kg/min | up to 100 |
| Dosing accuracy, % | 5.0 |
| Operating pressure, MPa | 0.4–0.8 |
| Air consumption, m³/min | 10 (loading), 5 (feeding) |
| Vacuum in mixing chamber, MPa | 0.03–0.07 |
| Explosive tank volume, L | 138 |
| Liquid additive tank, L | 6.7 |
| Feed hose (internal diameter × length) | 50 mm / 3 m |
| Feeding hose: Ø / length | 20–40 mm / up to 300 m |
| Inclination angle range, ° | 0–360 |
| Noise level (ejector), dB | ≤ 85 |
| Dimensions (L×W×H), mm | 760 × 830 × 1400 |
| Unloaded weight, kg | ≤ 150 |
| Service life, years | 7 |
| Climatic rating (GOST 15150-69) | UHL, category 5 |
The unit operates in non-hazardous areas (gas/dust-free). Initiation methods: NONEL, SENV, or electric blasting. Primer loading is manual; bulk delivery is pneumatic via Ulba-150I.
Contact our team to discuss configuration or request original spare parts for the Ulba-150I unit.
